[geomesa-dev] [JIRA] (GEOMESA-2454) Spark: cannot resolve 'CAST(`geom` AS STRUCT<`wkb`: BINARY>)' due to data type mismatch: cannot cast point to geometry

From: "Seth Fitzsimmons (JIRA)" <jira@xxxxxxxxxxxxxxxxxxxxx>
Date: Sat, 3 Nov 2018 18:26:46 +0000 (UTC)
Auto-submitted: auto-generated
Delivered-to: geomesa-dev@xxxxxxxxxxxxxxxx
List-archive: <https://dev.locationtech.org/mhonarc/lists/geomesa-dev>
List-help: <mailto:geomesa-dev-request@locationtech.org?subject=help>
List-subscribe: <https://dev.locationtech.org/mailman/listinfo/geomesa-dev>, <mailto:geomesa-dev-request@locationtech.org?subject=subscribe>
List-unsubscribe: <https://dev.locationtech.org/mailman/options/geomesa-dev>, <mailto:geomesa-dev-request@locationtech.org?subject=unsubscribe>

Title: Message Title

Seth Fitzsimmons created an issue

GeoMesa /

GEOMESA-2454

Issue Type:	Bug
Affects Versions:	2.0.2
Assignee:	Unassigned
Created:	03/Nov/18 2:26 PM
Priority:	Major
Reporter:	Seth Fitzsimmons

I have a case class intended to contain mixed geometries. I would expect to be able to create Points, Lines, Polygons (using st_make*) and map them to a Geometry type.

This works (with geom specifically set to be a Point):


                                                                import com.vividsolutions.jts.geom._
import org.apache.spark.sql.SparkSession
import org.locationtech.geomesa.spark.jts._

case class Container(lon: Double, lat: Double, geom: Point)

object Test extends App {
  val spark = SparkSession.builder
    .master("local[*]")
    .getOrCreate()
  import spark.implicits._
  spark.withJTS

  val df = List((-117.91915, 33.81196))
    .toDF("lon", "lat")
    .withColumn("geom", st_makePoint('lon, 'lat))

  val contained = df.as[Container]

  contained.show
}



When changing geom to be a more general Geometry, this fails:


                                                                package common

import com.vividsolutions.jts.geom._
import org.apache.spark.sql.SparkSession
import org.locationtech.geomesa.spark.jts._

case class Container(lon: Double, lat: Double, geom: /* only difference: */ Geometry)

object Test extends App {
  val spark = SparkSession.builder
    .master("local[*]")
    .getOrCreate()
  import spark.implicits._
  spark.withJTS

  val df = List((-117.91915, 33.81196))
    .toDF("lon", "lat")
    .withColumn("geom", st_makePoint('lon, 'lat))

  val contained = df.as[Container]

  contained.show
}



The Spark/GeoMesa portion of the stack trace is below.

Spark's TypedColumn docs suggest that I should be able to change the Column from TypedColumn[Any, Point] (which st_makePoint produces) to TypedColumn[Any, Geometry] by doing this:


                                                                st_makePoint('lon, 'lat).as[Geometry]

..but that results in the same error.


                                                                st_makePoint('lon, 'lat).cast(GeometryUDT)

similarly fails, but with a different error:


                                                                org.apache.spark.sql.AnalysisException: cannot resolve 'CAST(UDF(lon, lat) AS STRUCT<`wkb`: BINARY>)' due to data type mismatch: cannot cast point to geometry;;

I was ultimately able to work around the problem by introducing st_castToGeometry, based on the definition for st_castToPoint:


                                                                import com.vividsolutions.jts.geom._
import org.apache.spark.sql.{Column, SparkSession, TypedColumn}
import org.locationtech.geomesa.spark.jts._
import org.locationtech.geomesa.spark.jts.util.SQLFunctionHelper.udfToColumn

case class Container(lon: Double, lat: Double, geom: Geometry)

object Test extends App {
  val spark = SparkSession.builder
    .master("local[*]")
    .getOrCreate()
  import spark.implicits._
  spark.withJTS

  private val ST_CastToGeometry: Geometry => Geometry = g => g

  private val castingNames = Map(
    ST_CastToGeometry -> "st_castToGeometry"
  )

  def st_castToGeometry(geom: Column): TypedColumn[Any, Geometry] =
    udfToColumn(ST_CastToGeometry, castingNames, geom)

  val df = List((-117.91915, 33.81196))
    .toDF("lon", "lat")
    .withColumn("geom", st_castToGeometry(st_makePoint('lon, 'lat)))

  val contained = df.as[Container]

  contained.show
}




                                                                org.apache.spark.sql.AnalysisException: cannot resolve 'CAST(`geom` AS STRUCT<`wkb`: BINARY>)' due to data type mismatch: cannot cast point to geometry;
	at org.apache.spark.sql.catalyst.analysis.package$AnalysisErrorAt.failAnalysis(package.scala:42)
	at org.apache.spark.sql.catalyst.analysis.CheckAnalysis$$anonfun$checkAnalysis$1$$anonfun$apply$2.applyOrElse(CheckAnalysis.scala:93)
	at org.apache.spark.sql.catalyst.analysis.CheckAnalysis$$anonfun$checkAnalysis$1$$anonfun$apply$2.applyOrElse(CheckAnalysis.scala:85)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$transformUp$1.apply(TreeNode.scala:289)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$transformUp$1.apply(TreeNode.scala:289)
	at org.apache.spark.sql.catalyst.trees.CurrentOrigin$.withOrigin(TreeNode.scala:70)
	at org.apache.spark.sql.catalyst.trees.TreeNode.transformUp(TreeNode.scala:288)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$3.apply(TreeNode.scala:286)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$3.apply(TreeNode.scala:286)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$4$$anonfun$apply$11.apply(TreeNode.scala:335)
	at scala.collection.TraversableLike$$anonfun$map$1.apply(TraversableLike.scala:234)
	at scala.collection.TraversableLike$$anonfun$map$1.apply(TraversableLike.scala:234)
	at scala.collection.immutable.List.foreach(List.scala:392)
	at scala.collection.TraversableLike$class.map(TraversableLike.scala:234)
	at scala.collection.immutable.List.map(List.scala:296)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$4.apply(TreeNode.scala:333)
	at org.apache.spark.sql.catalyst.trees.TreeNode.mapProductIterator(TreeNode.scala:187)
	at org.apache.spark.sql.catalyst.trees.TreeNode.mapChildren(TreeNode.scala:304)
	at org.apache.spark.sql.catalyst.trees.TreeNode.transformUp(TreeNode.scala:286)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$3.apply(TreeNode.scala:286)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$3.apply(TreeNode.scala:286)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$4$$anonfun$apply$11.apply(TreeNode.scala:335)
	at scala.collection.TraversableLike$$anonfun$map$1.apply(TraversableLike.scala:234)
	at scala.collection.TraversableLike$$anonfun$map$1.apply(TraversableLike.scala:234)
	at scala.collection.immutable.List.foreach(List.scala:392)
	at scala.collection.TraversableLike$class.map(TraversableLike.scala:234)
	at scala.collection.immutable.List.map(List.scala:296)
	at org.apache.spark.sql.catalyst.trees.TreeNode$$anonfun$4.apply(TreeNode.scala:333)
	at org.apache.spark.sql.catalyst.trees.TreeNode.mapProductIterator(TreeNode.scala:187)
	at org.apache.spark.sql.catalyst.trees.TreeNode.mapChildren(TreeNode.scala:304)
	at org.apache.spark.sql.catalyst.trees.TreeNode.transformUp(TreeNode.scala:286)
	at org.apache.spark.sql.catalyst.plans.QueryPlan$$anonfun$transformExpressionsUp$1.apply(QueryPlan.scala:95)
	at org.apache.spark.sql.catalyst.plans.QueryPlan$$anonfun$transformExpressionsUp$1.apply(QueryPlan.scala:95)
	at org.apache.spark.sql.catalyst.plans.QueryPlan$$anonfun$1.apply(QueryPlan.scala:107)
	at org.apache.spark.sql.catalyst.plans.QueryPlan$$anonfun$1.apply(QueryPlan.scala:107)
	at org.apache.spark.sql.catalyst.trees.CurrentOrigin$.withOrigin(TreeNode.scala:70)
	at org.apache.spark.sql.catalyst.plans.QueryPlan.transformExpression$1(QueryPlan.scala:106)
	at org.apache.spark.sql.catalyst.plans.QueryPlan.org$apache$spark$sql$catalyst$plans$QueryPlan$$recursiveTransform$1(QueryPlan.scala:118)
	at org.apache.spark.sql.catalyst.plans.QueryPlan$$anonfun$2.apply(QueryPlan.scala:127)
	at org.apache.spark.sql.catalyst.trees.TreeNode.mapProductIterator(TreeNode.scala:187)
	at org.apache.spark.sql.catalyst.plans.QueryPlan.mapExpressions(QueryPlan.scala:127)
	at org.apache.spark.sql.catalyst.plans.QueryPlan.transformExpressionsUp(QueryPlan.scala:95)
	at org.apache.spark.sql.catalyst.analysis.CheckAnalysis$$anonfun$checkAnalysis$1.apply(CheckAnalysis.scala:85)
	at org.apache.spark.sql.catalyst.analysis.CheckAnalysis$$anonfun$checkAnalysis$1.apply(CheckAnalysis.scala:80)
	at org.apache.spark.sql.catalyst.trees.TreeNode.foreachUp(TreeNode.scala:127)
	at org.apache.spark.sql.catalyst.analysis.CheckAnalysis$class.checkAnalysis(CheckAnalysis.scala:80)
	at org.apache.spark.sql.catalyst.analysis.Analyzer.checkAnalysis(Analyzer.scala:92)
	at org.apache.spark.sql.catalyst.encoders.ExpressionEncoder.resolveAndBind(ExpressionEncoder.scala:257)
	at org.apache.spark.sql.Dataset.org$apache$spark$sql$Dataset$$deserializer$lzycompute(Dataset.scala:212)
	at org.apache.spark.sql.Dataset.org$apache$spark$sql$Dataset$$deserializer(Dataset.scala:211)
	at org.apache.spark.sql.Dataset$.apply(Dataset.scala:68)
	at org.apache.spark.sql.Dataset.as(Dataset.scala:418)
