| Modular W3C schema files in the XML editor [message #155877] |
Wed, 11 January 2006 14:34  |
 No real name
Messages: 2
Registered: July 2009 |
Junior Member |
|
|
I've been experimenting with loading modular xml schema into the Eclipse xml editor used in WTP 1.0, where a top level schema loads other schema using the xs:include statement.
If I load the top level schema file, elements defined in the schema files, that are included into the top level schema file, do not show up at the top level. The included elements are not visible in the outline view, and any document containing these elements will not validate against the top level schema file that contains the "include" statements. In the "graph" view, though, the included elements are listed.
If I remove the "include" statements and insert all of the elements defined in the included schema files into the top level schema file, then the elements show up, and validation works.
If I set up a modular set of files using DTD, in which a top level DTD file calls other DTD files via entity declarations, then all elements defined in the modular DTD files are available and validation works.
Is this a limitation of the current WTP XSD support?
Thanks,
Tom Ed White
|
|
|
|
|
