Sat, 16 August 2008 12:06

Eclipse User

Hi All,

I am new to TPTP (referred by google :>). I wonder if TPTP can help me to
the following.

I have a C++ application which I would like to profile by just inserting
logs or traces. I want to record the execution call graph and the time it
take to run each function. xml file will be generated

I want to visualize this in TPTP. Call graph with hotspot, table of
functions sorted by time taken, filtering etc.

I am thinking about writing some extender of TPTP to read in the xml file
I created and somehow talk to the TPTP framework to tell it about the
execution and timing data.

Am I on the right track? Can TPTP do this?

Thanks!

Re: Can TPTP do this? [message #134360 is a reply to message #134344]

Mon, 18 August 2008 13:16

Eclipse User

Hi Eric,

Instead of extender to read in the xml file, you can log the information in
the XML4Trace format
( http://www.eclipse.org/tptp/platform/documents/resources/pro filingspec/XML4Profiling.htm)
which can then be imported as regular profile file to TPTP and be visualized
in TPTP tables and graphs.

To generate an example of profiling file, you can profile a Java application
with TPTP 4.4.1 and specify to send profile data to a file (under the
monitor tab of the profiling configuration). It's a zipped text file and you
can unzip it to inspect its content.

Eugene

"Eric" <ws1088@gmail.com> wrote in message
news:e0b639f88d2b387d01184adb41eb5260$1@www.eclipse.org...
> Hi All,
>
> I am new to TPTP (referred by google :>). I wonder if TPTP can help me to
> the following.
>
> I have a C++ application which I would like to profile by just inserting
> logs or traces. I want to record the execution call graph and the time it
> take to run each function. xml file will be generated
>
> I want to visualize this in TPTP. Call graph with hotspot, table of
> functions sorted by time taken, filtering etc.
>
> I am thinking about writing some extender of TPTP to read in the xml file
> I created and somehow talk to the TPTP framework to tell it about the
> execution and timing data.
> Am I on the right track? Can TPTP do this?
>
> Thanks!
>

Re: Can TPTP do this? [message #134391 is a reply to message #134360]

Mon, 18 August 2008 19:48

Eclipse User

Thanks, I think XML4Trace will work for me.

Is there a C++ library/API which I can use to generate this format?

Thanks!

Re: Can TPTP do this? [message #135214 is a reply to message #134360]

Thu, 28 August 2008 17:32

Eclipse User

I tried Eugene's suggestion and profiled a sample java application. I got
a trcxml file and uncompress it and it has several .bin files (I assume
one .bin files represent one trace). However, I cannot uncompress the .bin
file.

Can you shed some light on how can I create my trcxml file with multiple
trace using C++ or perl (basically ASII). Thanks!

Re: Can TPTP do this? [message #135288 is a reply to message #135214]

Fri, 29 August 2008 21:47

Eclipse User

Eric,

The bin file is in compressed XML format (it's called binary file). You
can find the definition by check the below link:
https://bugs.eclipse.org/bugs/attachment.cgi?id=89144
https://bugs.eclipse.org/bugs/attachment.cgi?id=93126

These two links are the attachments of Bugzilla 196713, you can also check
the discussion on compressed file format by checking link:
https://bugs.eclipse.org/bugs/show_bug.cgi?id=196713

Hope it helps.

Thanks.

Re: Can TPTP do this? [message #135849 is a reply to message #135288]

Tue, 16 September 2008 10:11

Eclipse User

Hi Eric,

The source code for emitting trace XML fragments is in
org.eclipse.tptp.platform.jvmti.runtime/sec-native/src/JPIAg ent/PrintXML.cpp
(and PrintXML.h). It was not designed to be fully reuse butt take a look for
information on how to generate the events there.

Eugene

"Yunan, He" <yunan.he@intel.com> wrote in message
news:3978b90368aabf7c30607fadbfcc24d8$1@www.eclipse.org...
> Eric,
>
> The bin file is in compressed XML format (it's called binary file). You
> can find the definition by check the below link:
> https://bugs.eclipse.org/bugs/attachment.cgi?id=89144
> https://bugs.eclipse.org/bugs/attachment.cgi?id=93126
>
> These two links are the attachments of Bugzilla 196713, you can also check
> the discussion on compressed file format by checking link:
> https://bugs.eclipse.org/bugs/show_bug.cgi?id=196713
>
> Hope it helps.
> Thanks.
